Escaping characters in Makefile

TL;DR: visit this page for a short and concise version of this article.

I’m a big sucker for irrelevant nitpicks like properly quoting arguments in shell scripts. I’ve also recently started using GNU make as a substitute for one-line shell scripts (so instead of a bunch of scripts like build.sh, deploy.sh, test.sh I get to have a single Makefile and can just run make build, make deploy, make test).

As a side note, there’s an excellent Makefile style guide available on the web. I’m going to be using a slightly modified prologue suggested in the guide in all Makefiles in this post:

MAKEFLAGS += --no-builtin-rules --no-builtin-variables --warn-undefined-variables
unexport MAKEFLAGS
.DEFAULT_GOAL := all
.DELETE_ON_ERROR:
.SUFFIXES:
SHELL := bash
.SHELLFLAGS := -eu -o pipefail -c

make invokes a shell program to execute recipes. As issues of properly escaping “special” characters are going to be discussed, the choice of shell is very relevant. The Makefiles in this post specify bash explicitly using the SHELL variable, but the same rules should apply for all similar sh-like shells.

Quoting arguments

You should quote command arguments in make rule recipes, just like in shell scripts. This is to prevent a single argument from being expanded into multiple arguments by the shell.

$

cat Makefile

# Prologue goes here...

test_var := Same line?
export test_var

test:
	@printf '%s\n' $(test_var)
	@printf '%s\n' '$(test_var)'
	@printf '%s\n' $$test_var
	@printf '%s\n' "$$test_var"

$

make test

Same
line?
Same line?
Same
line?
Same line?

This is quite often sufficient to write valid recipes.

One thing to note is that you shouldn’t use double quotes " for quoting arguments, as they might contain literal dollar signs $, interpreted by the shell as variable references, which is not something you always want.

Escaping quotes

What if test_var included a single quote '? In that case, even the quoted printf invocation would break because of the mismatch.

$

cat Makefile

# Prologue goes here...

test_var := Includes ' quote

test:
	printf '%s\n' '$(test_var)'

$

make test

printf '%s\n' 'Includes ' quote'
bash: -c: line 0: unexpected EOF while looking for matching `''
make: *** [Makefile:11: test] Error 2

One solution is to take advantage of how bash parses command arguments, and replace every quote ' by '\''. This works because bash merges a string like 'Includes '\'' quote' into Includes ' quote.

$

cat Makefile

# Prologue goes here...

escape = $(subst ','\'',$(1))

test_var := Includes ' quote

test:
	printf '%s\n' '$(call escape,$(test_var))'

$

make test

printf '%s\n' 'Includes '\'' quote'
Includes ' quote

Surprisingly, this works even in much more complicated cases. You can have a recipe that executes a command that takes a whole other command (with its own separate arguments) as an argument. I guess the most common use case is doing something like ssh 'rm -rf $(junk_dir)', but I’ll use nested bash calls instead for simplicity.

$

cat Makefile

# Prologue goes here...

escape = $(subst ','\'',$(1))

test_var := Includes ' quote

echo_test_var := printf '%s\n' '$(call escape,$(test_var))'
bash_test_var := bash -c '$(call escape,$(echo_test_var))'

test:
	printf '%s\n' '$(call escape,$(test_var))'
	bash -c '$(call escape,$(echo_test_var))'
	bash -c '$(call escape,$(bash_test_var))'

$

make test

printf '%s\n' 'Includes '\'' quote'
Includes ' quote
bash -c 'printf '\''%s\n'\'' '\''Includes '\''\'\'''\'' quote'\'''
Includes ' quote
bash -c 'bash -c '\''printf '\''\'\'''\''%s\n'\''\'\'''\'' '\''\'\'''\''Includes '\''\'\'''\''\'\''\'\'''\'''\''\'\'''\'' quote'\''\'\'''\'''\'''
Includes ' quote

That’s somewhat insane, but it works.

Shell output

The shell function is one of the two most common ways to communicate with the outside world in a Makefile (the other being environment variables). This little escape function we’ve defined is actually sufficient to deal with the output of the shell function safely.

$

cat Makefile

# Prologue goes here...

escape = $(subst ','\'',$(1))

cwd := $(shell basename -- "$$( pwd )")

simple_var := Simple value
composite_var := Composite value - $(simple_var) - $(cwd)

.PHONY: test
test:
	@printf '%s\n' '$(call escape,$(cwd))'
	@printf '%s\n' '$(call escape,$(composite_var))'

$

mkdir "Includes ' quote" && \
    cd "Includes ' quote" && \
    make -f ../Makefile test

Includes ' quote
Composite value - Simple value - Includes ' quote

$

mkdir 'Maybe a comment #' && \
    cd 'Maybe a comment #' && \
    make -f ../Makefile test

Maybe a comment #
Composite value - Simple value - Maybe a comment #

$

mkdir 'Variable ${reference}' && \
    cd 'Variable ${reference}' && \
    make -f ../Makefile test

Variable ${reference}
Composite value - Simple value - Variable ${reference}

Environment variables

Makefiles often have parameters that modify their behaviour. The most common example is doing something like make install PREFIX=/somewhere/else, where the PREFIX argument overrides the default value “/usr/local”. These parameters are often defined in a Makefile like this:

param_name ?= Default value

They should be escaped and quoted when passed to external commands, of course. However, things get complicated when they contain dollar signs $. make variables may contain references to other variables, and they’re expanded recursively either when defined (for := assignments) or when used (in all other cases, including ?=).

$

cat Makefile

# Prologue goes here...

escape = $(subst ','\'',$(1))

test_var ?= This is safe.
export test_var

.PHONY: test
test:
	@printf '%s\n' '$(call escape,$(test_var))'
	@printf '%s\n' "$$test_var"

$

test_var='Variable ${reference}' make test

Makefile:15: warning: undefined variable 'reference'
Variable
Variable ${reference}

Here, $(test_var) is expanded recursively, substituting an empty string for the ${reference} part. One attempt to solve this is to escape the dollar sign in the variable value, but that breaks the "$$test_var" case:

$

test_var='Variable $${reference}' make test

Variable ${reference}
Variable $${reference}

A working solution would be to use the escape function on the unexpanded variable value. Turns out, you can do just that using the value function in make.

$

cat Makefile

# Prologue goes here...

escape = $(subst ','\'',$(1))

test_var ?= This is safe.
test_var := $(value test_var)
export test_var

.PHONY: test
test:
	@printf '%s\n' '$(call escape,$(test_var))'
	@printf '%s\n' "$$test_var"

$

test_var="Quote '"' and variable ${reference}' make test

Quote ' and variable ${reference}
Quote ' and variable ${reference}

This doesn’t quite work though when overriding variables on the command line. For example, this doesn’t work:

$

make test test_var='Variable ${reference}'

Makefile:16: warning: undefined variable 'reference'
make: warning: undefined variable 'reference'
Variable
Variable

This is because make ignores all assignments to test_var if it’s overridden on the command line (including test_var := $(value test_var)).

This can be fixed using the override directive for these cases only. A complete solution that works for seemingly all cases looks like something along these lines:

ifeq ($(origin test_var),environment)
    test_var := $(value test_var)
endif
ifeq ($(origin test_var),environment override)
    test_var := $(value test_var)
endif
ifeq ($(origin test_var),command line)
    override test_var := $(value test_var)
endif

Here, we check where the value of test_var comes from using the origin function. If it was defined in the environment (the environment and environment override cases), its value is prevented from being expanded using the value function. If it was overridden on the command line (the command line case), the override directive is used so that the unexpanded value actually gets assigned.

The snippet above can be generalized by defining a custom function that produces the required make code, and then calling eval.

define noexpand
ifeq ($$(origin $(1)),environment)
    $(1) := $$(value $(1))
endif
ifeq ($$(origin $(1)),environment override)
    $(1) := $$(value $(1))
endif
ifeq ($$(origin $(1)),command line)
    override $(1) := $$(value $(1))
endif
endef

test_var ?= This is safe.

$(eval $(call noexpand,test_var))

I couldn’t find a case where the combination of escape and noexpand wouldn’t work. You can even safely use other variable as the default value of test_var, and it works:

$

cat Makefile

# Prologue goes here...

escape = $(subst ','\'',$(1))

define noexpand
ifeq ($$(origin $(1)),environment)
    $(1) := $$(value $(1))
endif
ifeq ($$(origin $(1)),environment override)
    $(1) := $$(value $(1))
endif
ifeq ($$(origin $(1)),command line)
    override $(1) := $$(value $(1))
endif
endef

simple_var := Simple value

test_var ?= $(simple_var) in test_var
$(eval $(call noexpand,test_var))

simple_var := New simple value
composite_var := Composite value - $(simple_var) - $(test_var)

.PHONY: test
test:
	@printf '%s\n' '$(call escape,$(test_var))'
	@printf '%s\n' '$(call escape,$(composite_var))'

$

make test

New simple value in test_var
Composite value - New simple value - New simple value in test_var

$

make test test_var='Variable ${reference}'

Variable ${reference}
Composite value - New simple value - Variable ${reference}

$

test_var='Variable ${reference}' make test

Variable ${reference}
Composite value - New simple value - Variable ${reference}
